Main dimensions
Length hull 65.25 m
Breadth hull 62 m
Depth hull 8.0 m
Design draft 4.5 m

Survival conditions
Water depth 106 m
Air gap 15 m
Wave height 15 m
Current 0.51 m/s
Wind speed 51 m/s
Spudcan penetration 5 m

Main tank capacities
Fuel oil 800 m3
Drill water 3,000 m3
Potable water 450 m3
Preload 10,500 m3
Liquid mud 740 m3
Bulk mud/ cement 425 m3
Brine 200 m3
Base oil 200 m3

Variable and combined load
Variable and combined load operational 4,180 t
Combined drilling load
(independent of transverse position):
? Survival (independent of reach) 300 t
? Operating at 21.33 m extension 680 t
? Operating at 15.24 m extension 1,240 t

Legs
Leg length 147.4 m
Leg diameter 10 m
Spudcan area 150 m2

Jacking system
Number of pinions 54
Make
Type GDRLL-100/6

Fixation system
Make JXY
Type 5000

Cantilever system
Type JXY X-Y
Longitudinal reach 21.33 m
Transverse reach 12.2 m
